プログラムで表示されるテンプレートの場合など、リスト「li」の数が決まってい場合があります。
そのような場合でも、きれいにCSSだけで2列のリストを表示させることができるCSSのサンプルを作ってみました。
なお、nth-last-of-type(その種類の最後からn番目の要素に適応)など、ie8以下に適応されないスタイルを利用していますので、見た目もそうですが、スマートフォンでの利用を意識して作成したサンプルです。
完成形のCSSリスト
完成形はこのような形で、奇数の場合でもきれいに表示できます。リスト1つの場合

リスト2つの場合

リスト3つの場合

リスト4つの場合

リスト5つの場合

リスト6つの場合

と、きれいに表示できています。
可変を意識しながらリストを作るありがちな失敗例
数が増えた時に、borderが重なってしまったり、

奇数の時にborderが切れてたりします。

ポイントはliのborderの使い方です。
サンプルのCSSに簡単に説明を入れてみます。
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 |
li { //リストの頭を消す list-style: none; //並べる float: left; //幅を半分にする width: 50%; min-width: 130px; //高さがズレないように決め打ち、テキストを真ん中にする height: 45px; line-height: 45px; //右border、下border border-right: 1px solid #999; border-bottom: 1px solid #999; //borderを幅に含める -webkit-box-sizing: border-box; -moz-box-sizing: border-box; box-sizing: border-box; } //奇数の右borderを消す li:nth-child(even) { border-right: none; } //最後の下border、最後から2つ目の下borderを消す li:nth-last-child(1), li:nth-last-of-type(2) { border-bottom: none; } //最後から2つめの下が奇数の場合はborderをつける li:nth-last-of-type(2):nth-child(even) { border-bottom: 1px solid #999; } //リンクにスタイルをつける li a { display: block; padding-left: 15px; height: 45px; color: #333; font-weight: bold; font-size: 14px; } |
特に最後から2つめの下が奇数の場合はborderをつける部分がポイントです。
実際のソースはこちら
HTML
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 |
<!DOCTYPE html> <html lang="ja"> <head> <meta charset="utf-8"> <link rel="stylesheet" href="lite.css" type="text/css" /> </head> <body> <ul> <li><a href="#">ほげほげ</a></li> <li><a href="#">ほげほげ</a></li> <li><a href="#">ほげほげ</a></li> <li><a href="#">ほげほげ</a></li> <li><a href="#">ほげほげ</a></li> <li><a href="#">ほげほげ</a></li> </ul> </body> </html> |
CSS
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 |
/*Reset Style*/ html, body, div, span, object, iframe, h1, h2, h3, h4, h5, h6, p, blockquote, pre, abbr, address, cite, code, del, dfn, em, img, ins, kbd, q, samp, small, strong, sub, sup, var, b, i, dl, dt, dd, ol, ul, li, fieldset, form, label, legend, textarea, table, caption, tbody, tfoot, thead, tr, th, td, article, aside, canvas, details, figcaption, figure, footer, header, hgroup, menu, nav, section, summary, time, mark, audio, video { margin: 0; padding: 0; font-size: 100%; } /*base*/ body { line-height: 1.231; color: #333; font-family: sans-serif; font-family: 'MS PGothic', arial, sans-serif\0/; font-size: 13px; } a:link, a:visited, a:hover, a:active, a:focus { color: #333; text-decoration: none; } /*list*/ ul { margin: 10px ; border: 1px solid #999; border-radius: 10px; } ul:after { content: ""; display: block; clear: both; } li { list-style: none; float: left; width: 50%; min-width: 130px; height: 45px; line-height: 45px; border-right: 1px solid #999; border-bottom: 1px solid #999; -webkit-box-sizing: border-box; -moz-box-sizing: border-box; box-sizing: border-box; } li:nth-child(even) { border-right: none; } li:nth-last-child(1), li:nth-last-of-type(2) { border-bottom: none; } li:nth-last-of-type(2):nth-child(even) { border-bottom: 1px solid #999; } li a { display: block; padding-left: 15px; height: 45px; color: #333; font-weight: bold; font-size: 14px; } |
注意するのは、テキストが2行になる場合は、高さがずれてしまうので、どうしても2行になる場合は、高さを合わせるCSSを指定するか、heightLine.jsのような、JSでliの高さを揃える処理を入れる必要があります。
CSSで作る可変リストのサンプルでした。
